Section placed on a rolling dies.
Side roll moves up for pre bending.
Further position achieved for final dimensions.
Pusher arrangment used for coil forming.
Rolling in process
Rolling complete
The pre bending / edge bending and rolling can be performed in the same machine.
The machine frame is built from all tested steel plate material. This frame is subjected to stress releaving, sand blasting and epoxy primer painted for corrosion free long lasting machine life. The complete body is machined in cnc machine to achieve built in accuracy.
The side roll up-down position is indicated by digital meter / HMI provided on control desk.
In this type of model, all hydrualic actuators movement are through direction control solinoid valves.
All our machine rolls are mounted in heavy duty roller bearings. Each roller is fitted with two bearing per side (four bearing per roller).
The pusher roller assembly can be given as a option for coil forming application.
An optional feeder table can facilitate loading and machine operation by a single person only.
